Multi-gap PQ-core design

This Multi-gap PQ-Core Design Tool simplifies complex magnetic component engineering directly in your web browser. By entering the ideal core dimensions, gap conditions, and materials, the platform instantly calculates precise core factors, magnetic properties, and essential physical parameters. This automated process eliminates manual calculations to accelerate your magnetic design workflow.

Input the core dimensions:

A	B	C	D	E	F	G	H	I

Input the multi-gap conditions:

1. Number of the central stick cores:

For symmetry concern, the number should be even.

2. The spacer thickness (mm):

3. The center gap G3 (mm):

Select the material grade:

Output the results:

Core factors:

C1 =

mm⁻¹

C2 =

mm⁻³

Effective core parameters:

Ae =

mm²

Le =

Ve =

mm³

Amin =

mm²

Magnetic properties:

μe =

AL =

nH/N²

Multi-gap PQH-core product series in homogeneous core materials

Number of central stick cores: 2 unit: mm
Core type	Dim. ID A/2B	A	B	C	D	E	F	G	I	Spacer thickness	Center gap G3	Gapping size	AL(nH/N²)
Core type	Dim. ID A/2B	A	B	C	D	E	F	G	I	Spacer thickness	Center gap G3	Gapping size	P453	P53	P61
PQH	30/30	30.00	15.00	23.00	13.30	25.50	11.70	20.70	6.00	0.40	~0.4	0.20	195	186	181
										0.60	~0.6	0.30	137	133	130
										1.00	~1.0	0.50	90	88	87
	40/40	40.50	20.00	28.04	15.00	36.80	14.85	29.00	6.60	0.40	~0.4	0.20	246	233	227
										0.60	~0.6	0.30	173	166	163
										1.00	~1.0	0.50	112	110	108
	50/50	50.00	25.00	32.00	20.00	44.00	18.10	32.50	8.60	0.60	~0.6	0.30	295	282	276
										1.00	~1.0	0.50	190	184	182
										1.50	~1.5	0.75	135	133	131

Reference:
IEC 60205: 2016 Calculation of the effective parameters of magnetic piece parts
